Dual Energy X-Ray Inspection System for Tiny Bones
Compact design for detect residual bones left in meat processing, such as clavicle, fan bone, calcified bones, etc.
Detecting small, hard, and calcified bones in the poultry and meat processing industries poses a challenge due to their low density and diverse shapes, which can be affected by factors such as age, breed, and specific cuts of meat.
The Foodman Dual Energy X-ray Inspection System is a progressive solution specifically designed for the modern poultry industry. This X-ray machine is capable of detecting calcified bones, hard bones, and small bones in poultry products, including boneless raw meats like chicken breasts, legs, and wings, as well as processed items such as chicken nuggets, sausages, and meat patties.
The system ensures quality and safety by improving the detection of non-metallic contaminants, allowing for the accurate identification and removal of even the tiniest foreign objects and bones.
APPLICATIONS
chicken breast
boneless chicken wings
sausages
meat patties
TECH SPECS
Model: FXR-BN30
X-Ray Tube:350W
X-ray Detector:0.1, 0.2, 0.4, 0.8mm TDI Dual Energy
Max Product Width:300mm
Max Product Height:170mm
Conveyor Belt Speed:5-40m/min
Sensitivity(mm)
Calcified bone: 1.0mm
Fan bone: 2.0 mm
Rib bone: 2.0 mm
Wishbone: 2.0 mm
Stainless Steel Wire: 0.2*2 mm
Stainless Steel Ball: 0.3 mm
Aluminum: 0.7 mm
Ceramic: 0.8mm
Glass: 0.8mm
Operation Display:17-inch colored touch screen, Windows System
Power Supply:AC220V, 2Kv, 50/60Hz
Rejector:Support various rejector
Waterproof:Level IP66
Operating Requirement Temperature：-10℃～40℃，Humidity：30%～90%
Main Structure: SUS304 Stainless Steel
Connectivity:Ethernet/IP (EIP)/USB/TCP/IP Modbus TCP/RTU
X-ray Emissions:< 1uSv/hr
KEY FEATURES
Dual Energy Technology
Employs progressive dual-energy X-ray technology to enhance the system’s capability to distinguish between bones and other low-density materials such as meat and cartilage.
Bone Detection Precision
Fitted with advanced detectors and algorithms, it is capable of identifying even the tiniest bones, ensuring the safety and quality of the product.
Durability and Hygiene
Constructed from robust materials, this system is designed for food-grade environments. Its waterproof and dustproof features facilitate easy maintenance.
Minimal False Reject Rates
By reducing false rejects, it optimizes production efficiency and enhances product yield, effectively minimizing waste.
Safe and Reliable
Our X-ray machine complies with food safety regulations, maintaining X-ray leakage below 1 μSv/hour to meet stringent FDA and CE standards. You can trust our system to uphold the highest food safety benchmarks.
High Throughput Efficiency
Tailored for large-scale poultry processing, the Foodman Dual Energy X-Ray Inspection System can inspect up to 120 pieces per minute. This high throughput reduces bottlenecks and increases overall productivity while ensuring accurate inspections.
What Makes FOODMAN X-RAY INSPECTION SYSTEM DIFFERENT?
AI Based Technology
