X-Ray Inspection System for Tiny Fish Bone
Identify foreign objects in fish meat and detect any fish bones remaining after processing. An external high-definition display screen facilitates manual inspection for added convenience.
The Foodman X-Ray Inspection System for Fishbone is expertly designed to detect small fishbones within fish meat with remarkable precision and speed, making it an indispensable tool for fish processors seeking to enhance product safety and quality.
This system is highly versatile and adaptable, capable of inspecting a wide range of products, including fillets, whole fish, and processed fish items, making it ideal for various production environments. Its flexibility boosts operational efficiency while maintaining the highest safety standards.
Featuring ultra-high-resolution imaging and TDI (Time Delay Integration) technology, the system produces highly detailed images that enable the accurate identification of fishbones, even those that are often challenging to detect. Utilizing Foodman’s proprietary FIAP (Foodman Intelligent Algorithm Platform), the Foodman X-Ray Inspection System further enhances detection accuracy, ensuring that no fishbone is missed.
APPLICATIONS
tunny
salmon
cod
sardine
TECH SPECS
Model: FXR-YC Series
X-ray source: 80kv，350w
Detector: 0.1mm TDI detector
Channel width: Maximum width 400mm
Channel height: Maximum height 170mm
Conveyor belt speed:5-30 m/min
Weight/size of the product to be detected:Maximum 10kg
Sensitivity(mm):
Fishbone 0.1mm
Stainless steel ball 0.2mm
Stainless steel wire 0.1mm*2
Ceramic, glass balls 0.8m
Operation instructions: Windows system, 50-inch HD external screen, 17-inch color touch screen
Support data: interface LAN Port ，USB port
Protection:Protection cabin
Power supply: Single phase AC220V/110V, 50-60Hz
Rejection metho: SUS304 stainless steel
Working environment:Temperature -10℃~40℃, humidity 30~90%
Waterproof: level Conveyor is IP66, other parts are IP54
Equipment material: SUS304 stainless steel
Light source leakage:< 1uSv/h
KEY FEATURES
Specialized Fish Bone Detection
This system is specifically designed to identify even the smallest and most difficult fish bones, including tiny rib bones and calcified bones, guaranteeing that fish products are free of bones.
Versatile Design
Suitable for detecting bones in various fish products, whether raw or processed, this system upholds the highest standards of quality and safety.
AI-Powered Algorithms
It features FIAP image processing technology integrated with AI algorithms for real-time, accurate identification of fish bones across different types of fish.
User-Friendly Interface
Foodman employs the latest Windows operating system, equipped with a 50-inch 4K ultra-clear display and a 17-inch full-color touchscreen for superior image clarity. The streamlined, intuitive interface ensures ease of use, prevents data loss, and includes a built-in backup function for added security.
Advanced FLAP Technology
The Foodman X-Ray Inspection System leverages FIAP image processing technology, elevating detection accuracy to new heights, ensuring a thorough and reliable inspection process while enhancing product safety and quality with every scan.
Automatic Learning
The system automatically adjusts detection parameters based on real-time data, refining detection models and improving performance without the need for manual intervention.
What Makes FOODMAN X-RAY INSPECTION SYSTEM DIFFERENT?
AI Based Technology
