X-Ray Inspection System for Small Sachets
Engineered for X-ray inspection of compact packaged products and multi-lane applications across the food, pet food, pharmaceutical, and personal care industries.
Discover a reliable, high-tech solution for foreign body detection in packaged products with our innovative Food X-Ray Inspection System. Using advanced penetration capabilities, the system effectively identifies contaminants such as metals (Fe, non-Fe, stainless steel), bones, glass, ceramics, stones, sand, hard，plastics, and desiccants.
Widely applied across food packaging, pharmaceuticals, and light industries, this X-ray machine ensures product quality and reinforces consumer safety.
Designed for broad adaptability, our food X-ray inspection equipment supports a diverse range of packaged items, including cheese, biscuits, chips, infant foods, seasonings, spices, meatballs, fish balls, meat, poultry, sausages, bagged coffee, solid drinks, and more. Enhance your quality control measures with our progressive X-ray technology for precise, dependable safety inspections.
APPLICATIONS
boxed products
bagged products
hard plastic packaged products
glass packaged products
TECH SPECS
Model: FXR-3017
X-Ray Tube: 40-120KV
Aperture Size: Width: 300mm
Height: 170mm
Working Speed: 10-70m/min
Sensitivity(mm):
Stainless Steel Ball: Ф0.3
Stainless Steel Wire: Ф0.2*2
Ceramic: Ф1.0
Glass: Ф1.0
Operation: 17-inch colored touch screen, Windows System
Support data interface: LAN Port, USB Port
Power Supply: AC220V±10% 50Hz(60Hz), 1.5KVA Max
Rejector: Sound and indicator/stopping machine/rejector
Waterproof Level: IP66 for tunnel, IP54 for rest part
Operating Requirement: Temperature：-10℃～40℃，Humidity：30%～90%
Main Structure: SUS304 Stainless Steel
KEY FEATURES
Accurate Contaminant Detection
This system is highly effective at identifying a variety of foreign objects, such as metals, glass, stones, bones, ceramics, hard plastics, and rubber in packaged products, ensuring both food safety and quality.
Robust and Reliable Construction
Engineered with a sturdy design that incorporates waterproof and dustproof capabilities (IP66 rating for the tunnel), this system is well-suited for demanding production environments.
Broad Industry Applications
Ideal for sectors including food packaging, pharmaceuticals, and light industries, this X-ray inspection system offers extensive versatility across multiple applications.
High Throughput Efficiency
Designed for fast-paced production settings, it can inspect a substantial number of packaged products per minute while maintaining detection accuracy.
User-Friendly Interface
Equipped with a large, full-color 17-inch touchscreen, the intuitive interface makes operation straightforward, allowing users to easily manage and adjust settings.
Reduced False Reject Rate
Utilizing advanced AI algorithms, the system effectively minimizes false rejects by accurately distinguishing only contaminated or defective products, thereby optimizing production yield and minimizing waste.
What Makes FOODMAN X-RAY INSPECTION SYSTEM DIFFERENT?
AI Based Technology
